4T/H Biomass Straw wood Pellet Production Line In The Philippines

Wood Pellet Production Line In The Philippines

According to the current market demand, the client of this project, a Philippine agricultural company, invested 83,000 US dollars to use idle sites to build a biomass straw wood pellet production line project with an annual output of 10,000 tons.

The raw materials of this biomass straw wood pellet production line in the Philippines project include wood boards, straw, sawdust, wood corners, etc., with a moisture content of about 10%~12%. After pelleting by the pellet machine, the moisture content can reach 6%~8% (the quality of biomass fuel requires a moisture content of less than 8%). According to the customer, depending on the actual situation, rice husks, peanut shells, leaves and other raw materials are sometimes added.

After the completion of this wood pellet mill plant project, there will be 5 employees, one shift a day, each shift working 8 hours, and 300 days of production per year.

capacity

investment

location

project type

Among them, the office and living area, production area, etc. are all based on the existing site. The specific composition table after the completion of this straw wood pellet production line in the Philippines project is shown in the table below.

Engineering ContentConstruction Content
Main EngineeringProduction WorkshopCovering an area of ​​3400m2, 1F, divided into office area and production area according to functional zoning
Storage and Transportation EngineeringWarehouseCovering an area of ​​3270m2, 1F, used for stacking raw materials such as straw and sawdust and producing shaped biomass pellets
Public EngineeringWater SupplyMunicipal Water Supply
Power SupplyMunicipal Power Supply
Environmental Protection EngineeringWastewater treatmentSeptic tank
Waste gas treatmentUse “gas hood + bag dust collector 15m high exhaust pipe P1” for treatment, and strengthen mechanical ventilation of workshops and greening of factory areas
Noise controlSound insulation, vibration reduction and other measures
Solid waste treatmentGeneral solid waste room (10m2), hazardous waste temporary storage room (5m2), garbage bin

The product of this wood pellet production line in the Philippines project is formed biomass pellets, which are environmentally friendly pellet fuels with the advantages of small size, high heat, low cost, low environmental pollution, high combustion efficiency, easy combustion, low residual carbon, high energy density, and can be directly used in combustion boilers. It can be used to replace fossil fuels.

Product NameProduct Output (t/a)ColorSpecifications (mm)Packing Quantity (kg/bag)
Particle Size (D)Length (L)
Molded Biomass Pellets10000Gray52540

The indicators of biomass pellets produced by this project can meet the requirements of “Quality Classification of Biomass Solid Molded Fuels”. The specific product parameters are shown in the table below.

Product NameCalorific Value (MJ/kg)Moisture Content (%)Density (kg/m3)Ash Content (%)Sulfur Content (%)Nitrogen Content (%)Chlorine Content (%)
Biomass Pellets≥14.6≤15≥800≤6≤0.1≤1.0≤0.03

The production equipment required for the wood pellet production line in the Philippines project is shown in the table below.

NumberEquipment nameModelQTY
1Slicing and crushing machine/1 set
2Ring die pellet production line (including bucket elevator, pellet machine, conveyor belt)MZLH768 type1 line
3Scale/1 set

Capacity matching:

This project sets up a biomass pellet production line, and the equipment production time is 300 days per year (8h/shift×1 shift). At the same time, the hourly pelletizing capacity of this biomass pellet production line is 5kg. It is estimated that the annual production capacity of this project can reach 12,000 tons under full load, which can meet the production capacity of 10,000 tons/year of biomass pellets.

The production process of biomass pellets in this wood pellet production line in the Philippines project does not require the addition of binders, anti-slag agents and other auxiliary materials. The main raw and auxiliary materials required for the project production are detailed in the table below.

Serial numberNameConsumptionSource
1Straw, planks, sawdust and other wood10550t/aAmong them, straw comes from surrounding farmers; planks and sawdust come from leftovers from timber mills

The material balance analysis of this wood pellet production line in the Philippines project is detailed as follows.

NumberInputOutput
Material nameQTY (t/a)Material nameQTY (t/a)
1Straw, planks, sawdust and other wood10550ProductMolded biomass pellets10000
2//Waste gasCrushing dust6.69
3//Pelletizing dust6.69
4//Water evaporation436.62
5//Solid wasteImpurities1
6//Defective products99
Total/10550//10550

Brief description of the process flow:

  1. Sorting: Since the raw materials required for the project may carry some impurities such as stones and plastics, they are manually sorted before crushing to pick out impurities such as stones and plastics.
  2. Crushing: Since the purchased crop straw, waste wood boards, sawdust and other raw materials are large in size and cannot be directly used in the granulation process, so as not to affect the normal operation of the subsequent granulation process, it is necessary to use crushing equipment to crush the raw materials into small sizes first, which is convenient for the subsequent granulation process. The crushing system is equipped with a discharge conveyor.
  3. Silo: Since the particle size of the crushed raw materials is small, in order to reduce the generation of dust, the belt is used to transport them to the silo for feeding.
  4. Pelleting: The existing process control technology allows the crushed materials to be directly used in production without drying pretreatment; therefore, the crushed materials stored in the silo are conveyed to the silo of the extrusion molding machine through a closed conveyor, and then conveyed to the small silo of the extrusion molding equipment through the scraper conveyor and spiral conveyor of the molding machine. The extrusion molding adopts a vertical ring die multi-hole rotary extrusion method.
  5. Discharge cooling: The temperature of the molded fuel just out of the solid molding machine is 75-85℃. This state is easy to break and is not suitable for storage and transportation. The task of the cooling process is to cool down the high-temperature product after processing and molding so that its temperature can reach the conditions for packaging and storage. The natural cooling method is used in the entire process to make its temperature reach the conditions for packaging and storage.
  6. Packaging and storage: The molded particles are bagged and placed in the finished product storage area for storage.

Water supply and drainage

Water supply: The wood pellet production line in the Philippines project production process does not require water. Domestic water is provided by the municipal water supply pipeline, and its annual water consumption is about 75m3.

Drainage: The wood straw pellet production line in the Philippines project production process does not require water. The main wastewater generated is domestic sewage. After being collected in the septic tank, the domestic sewage is regularly cleaned and used for fertilizing the surrounding farmland.

Energy

Power supply: The power supply of this project is provided by the municipal power grid, and its annual power consumption is about 350,000 Kw∙h/a.

The production area of this wood biomass pellet production line in the Philippines project is relatively concentrated, and the production and office areas are separated. The production workshop is divided according to function, mainly into production area and office area, and the production area is arranged according to the production process.

This project is based on the premise of meeting the production process, considering safety and sanitation requirements, combining the natural terrain conditions of the project site, and dividing and combining various facilities according to different functions, striving to make the layout compact and reasonable, save land, facilitate production, and facilitate management.

Its plane design layout of this wood pellet production line in the Philippines is reasonable, logistics is smooth, and sanitary conditions, transportation, safety, and fire protection meet the needs of enterprises and industry requirements.

The prospects for carrying out wood pellet production line in the Philippines are very broad. With the transformation of the global energy structure and the improvement of environmental awareness, biomass pellets, as a clean and efficient form of energy, are gradually gaining favor in the market. As a developing country, the Philippines has a growing demand for renewable energy, and the government also strongly supports the development of renewable energy, which provides a good policy environment for the biomass pellet processing industry.

Market demand and policy support

The Philippine government’s support policy for renewable energy provides a strong guarantee for the biomass pellet processing industry. With the transformation of the global energy structure and the improvement of environmental awareness, biomass pellets, as a renewable energy, will gradually replace traditional fossil energy and become an important member of the future energy market. In addition, the Philippines is rich in agricultural and forestry resources, which provides a guarantee for the supply of raw materials for biomass pellets.

Market size and industry status

At present, the global biomass pellet market shows a trend of sustained growth. In 2023, the global biomass pellet market sales reached US$8.8 billion, and it is expected to reach US$14.8 billion in 2030, with a compound annual growth rate of 7.5%. As an important economy in Southeast Asia, the Philippines’ market size is not specifically mentioned, but considering its geographical location and economic development level, it is expected to occupy a certain proportion of the market share in Southeast Asia.

Technical level and production equipment

The continuous innovation and progress of biomass pellet processing technology provides entrepreneurs with more development opportunities and space. Modern biomass pellet processing technology includes chipping, crushing, drying, pelletizing, cooling, packaging and other links, each of which is equipped with a strict quality monitoring system to ensure the quality of the product. In addition, the agricultural and forestry machinery and equipment market in the Philippines also provides the necessary equipment support for biomass pellet processing.
