Waste Wood Pellet Manufacturing Project in Belgium

RICHI MACHINERY

The First Call – “I Have Access to Cheap Bark and Construction Waste”

The client called us in August 2023. He had been running a small waste management business for twelve years. He noticed that sawmills in Wallonia were paying to dispose of bark. Construction sites were paying to haul away wood waste.

He had a building (5,000m² total site, 3,000m² built). He had spring water from a nearby source, grid electricity, and a septic system. He had saved about $180,000.

His question: “Can I set up a 1t/h waste wood pellet manufacturing project in Belgium that runs on bark and construction waste?”

We asked about the raw material. He sent samples. The bark was 20-25% moisture – too wet for direct pelleting. The construction wood waste was dry (10-12% moisture) but contained nails and sometimes paint. Theshavings and sawdust were ideal (10-12% moisture).

We told him yes. A 1t/h waste wood pellet manufacturing project in Belgium would need a few extra steps: drying for the bark, metal separation for the construction waste, and careful quality control to reject painted material.

RICHI MACHINERY

Raw Materials – Three Feedstocks, Low Cost

The client set up collection agreements with three sawmills and two construction waste sorting facilities.

The bark is the cheapest – almost free. The sawmill pays the client to take it ($5/ton is essentially a transport fee). The construction waste is also low-cost because the sorting facility saves disposal fees.

Total input 2,510 tons, output 2,500 tons. The 10-ton difference accounts for:

• Dust collected: 3.424 tons (returned to production)
  -Rejects: 6.541 tons (returned to crusher)
  -Particulate emissions: 0.035 tons

The client also has staff dormitory for 10 employees who live on site

RICHI MACHINERY

Why Drying Is Necessary – And How We Designed It

At 20-25% moisture, bark cannot be pelleted directly. The client needed a dryer.

We specified a small rotary drum dryer (1m diameter x 4m length) using biomass fuel. Since the client produces pellets, the dryer can burn self-produced pellets or the driest bark.

Dryer specifications:

• Type: Rotary drum, direct heating
• Length: 4 meters
• Diameter: 1 meter
• Fuel: Self-produced pellets or dry bark
• Inlet moisture: 20-25%
• Outlet moisture: 12-15%
• Retention time: 15-20 minutes

The dryer is a significant investment in this 1t/h waste wood pellet manufacturing plant project in Belgium – $18,000 including the furnace. But without it, the client couldn’t use the cheap bark (80% of his feedstock).

RICHI MACHINERY

Equipment List – Complete Small Line

Equipment price (EXW Qingdao port): $95,000 USD

The client bought the wheel loader locally in Belgium.

Shipping: Two 40-foot containers. Departed Qingdao September 15, 2023. Arrived Port of Antwerp, Belgium on October 28, 2023. Sea freight: $4,500 USD. Inland trucking to Wallonia (about 120km) added $800 USD.

RICHI MACHINERY

Facility Layout – 5,000m² Total Site

The client’s site was 5,000m² with 3,000m² built area.

RICHI MACHINERY

Process Flow – Four Feedstocks, One Line

Here’s how the 1t/h waste wood pellet manufacturing project in Belgium actually runs.

Step 1 – Sorting and pre-treatment
Bark goes to the dryer. Construction waste passes through a magnetic separator to remove nails and screws. Shavings and sawdust go directly to the crusher.

Step 2 – Drying – for bark only
Bark passes through the rotary drum dryer. Inlet moisture: 20-25%. Outlet moisture: 12-15%. The dryer operates only when processing bark.

Step 3 – Crushing
All materials are fed into the crusher. Output size: 20-30mm chips. The crusher is enclosed with dust collection.

Step 4 – Grinding
Crushed material is fed into the hammer mill. Output size: 5-10mm particles.

Step 5 – Pelleting
Ground material is fed into the wood pellet extruder machine. Single mill produces 1 t/h. Die size: 8mm diameter, 20-40mm length.

The pelleting process uses friction heat (80-100°C) to soften the lignin, which acts as a natural binder. No added binders or additives.

Step 6 – Bagging
Pellets are bagged using the wood pellet bagging machine. The client sells about 60% in 15kg bags and 40% in bulk.

RICHI MACHINERY

Dust Collection – Baghouse with 15m Stack

The client installed a single baghouse filter with a 15m exhaust stack. Belgian regulations require 15m stacks for facilities of this size.

System specifications:

• Type: Pulse-jet baghouse
• Collection efficiency: 99% on particles >0.1μm
• Exhaust stack: 15m height

Emissions:

• Collected dust: 3.424 tons/year ( returned to production)
• Stack emissions: well below Belgian EPA limits (Particulate matter emissions 0.035 t/yr)
• Fugitive dust: minimal due to enclosed equipment

RICHI MACHINERY

The Belgian Market for Wood Pellets

Belgium is a mature pellet market. The country has:

• Over 100,000 pellet heating systems installed
• A well-established ENplus certification system
• Government subsidies for biomass heating (up to €2,500)
• Export opportunities to the Netherlands and Germany

The client’s current customers:

• A pellet distributor in Charleroi (100 tons/month)
• Hardware stores in Wallonia (60 tons/month)
• Direct sales to households (48 tons/month)

The client plans to add a second pellet mill in 2025 to reach 2 t/h. He also plans to pursue ENplus A1 certification for export to Germany, where pellet prices are 10-15% higher.

RICHI MACHINERY

What the Client Learned

We spoke with the client in July 2024, five months after startup. Here are his observations.

What worked well:

• The cheap bark. “I pay $5/ton for material that sawmills used to pay $20/ton to dump. The dryer pays for itself.”
• The magnetic separator. “Construction waste had nails. The magnet catches them before they damage the mill.”
• The single-mill configuration. “Simple. One mill, one set of problems.”

What he would change:

• “I should have bought a larger dryer.” The current dryer processes bark slowly. He’s looking at a larger unit ($12,000).
• “The construction waste sometimes has paint.” He rejects about 5% of construction waste loads. He’s training suppliers to pre-sort better.
• “I need a moisture meter for the dryer output.” He runs without measuring. He’s ordering an inline meter ($1,500).

RICHI MACHINERY

What We Provided

For this 1t/h waste wood pellet manufacturing project in Belgium, we delivered:

• Process design – Multi-feedstock line with drying and metal separation.
• Equipment package – Crusher, hammer mill, dryer, wood pellet press, bagging machine, conveyor, baghouse, stack, magnetic separator.
• Installation supervision – Our engineer spent 12 days in Wallonia.
• Operator training – Two days on moisture management, die changes, and Belgian compliance requirements.
• Spare parts kit – One spare die, bearings, belts, and filter bags.

RICHI MACHINERY

Thinking About a Waste Wood Pellet Project in Belgium?

If you’re looking at a 1t/h waste wood pellet manufacturing project in Belgium – or anywhere in Western Europe – here’s what we’ve learned from this project:

• Bark is cheap but needs drying. Budget for a dryer if bark is your primary feedstock. The math works – bark at $5/ton vs sawdust at $35-45/ton.
• Construction waste requires metal separation. A magnetic separator costs $2,000-3,000 and prevents mill damage.
• Reject painted wood. Paint contains chemicals that create harmful emissions and lower pellet quality. Train your suppliers.
• Belgium has a strong pellet market. With government subsidies and high energy prices, pellets are competitive.
• ENplus certification is valuable. Belgian customers pay €420-480/ton ($455-520) for certified pellets vs €300-350 ($325-380) for uncertified.

The client in Wallonia is already profitable. He’s expanding. If you have access to low-cost bark or construction waste and a market for premium pellets, this model works.

Contact us for a site assessment or equipment quote. We can provide references from this biomass pellet project upon request.
