Tofu Cat Litter Production Line In Brazil

RICHI MACHINERY

overview

The tofu cat litter production line in Brazil project uses the existing idle factory buildings for production. The project covers an area of ​​2200m2 and the building area of ​​the factory is 2000m2, mainly including workshops, offices, warehouses, etc. 52 sets of main equipment were purchased, using bean dregs, corn starch, etc. as raw materials, and after feeding, mixing, granulation, drying, screening, adding flavors, packaging and other processes, 20,000 tons of cat litter are produced annually.

The labor quota of this project is 10 people, working 300 days a year, 8 hours per shift, one shift system, and the annual working time is 2400 hours.

RICHI MACHINERY

Project construction content

The tofu cat litter production line in Brazil project covers an area of 2,200 square meters, mainly including workshops, offices, etc., and purchases 52 sets of main equipment. The project produces 20,000 tons of cat litter annually. The project composition is classified into main engineering, auxiliary engineering, public engineering, and environmental protection engineering as shown in the following table:

RICHI MACHINERY

Raw and auxiliary materials and energy consumption

The main raw and auxiliary materials and energy consumption of this tofu cat litter production line in Brazil project are shown in the table below.

Note:

The flavors used in this project are edible flavors. Edible flavors are made by carefully blending natural flavors and synthetic flavors with reference to the flavors of natural foods. The flavors used in this project are liquid flavors, the main components of which are benzaldehyde, vanillin, jasmine, peach aldehyde, and vegetable oil.

RICHI MACHINERY

Main equipment for tofu cat litter production line in Brazil

The main cat litter making machines of this tofu cat litter production line in Brazil project are shown in the table below:

RICHI MACHINERY

Energy consumption

(1) Power supply:

The project consumes 1.2 million kWh of electricity per year, which is provided by the local power supply station.

(2) Gas supply:

The tofu cat litter production line in Brazil project uses liquefied natural gas, which is purchased in cylinders, with a gas consumption of 40t/a.

(3) Heating:

The drying heating of the project is direct heating by natural gas combustion.

RICHI MACHINERY

Plant layout

This tofu cat litter production line in Brazil project installs equipment in the existing plant of the enterprise for production, and the project covers an area of 2,200m2. The project layout fully considers the requirements of production technology and public facilities. Each link is compactly connected, and the material transportation distance is short, which is convenient for energy saving and consumption reduction, and improves production efficiency.

At the same time, it takes into account the production and office environment within the plant, and also takes into account the environment outside the plant. From the perspective of convenient production, safe management, and environmental protection, the layout is reasonable.

RICHI MACHINERY

Brazilian cat litter production line project process design

The tofu cat litter process flow of this tofu cat litter production line in Brazil project is described as follows:

1. Loading: The raw materials of this project include bean dregs, corn starch, etc. The raw materials are purchased by truck and stored in the workshop. The packaging bags are opened manually and put into the feeder according to the corresponding proportion.
2. Mixing: This process is mainly to fully mix the raw materials. The mixer is a closed equipment. In order to make the raw materials stick together and mix efficiently, water needs to be added before mixing (water is added to the mixer by controlling the water pump). The semi-finished products produced in the mixing process are transported to the granulation process via a closed conveyor belt.
3. Granulation: This project adopts dry granulation. The granulator is closed during operation, and the raw materials themselves contain a certain amount of water. The semi-finished products produced in the granulation process are transported to the drying process via a closed conveyor belt.
4. Drying: Since the raw materials themselves contain a certain amount of moisture, the semi-finished cat litter particles produced in the granulation process need to be dried. The drying heat source uses liquefied natural gas and direct drying method. The drying temperature is 80℃~90℃ and the drying time is about 10~15min. The semi-finished cat litter particles after drying are cooled by air and then conveyed to the screening machine through a closed conveyor belt.
5. Screening: The screening machine is a closed structure. After the cat litter enters the screening machine, it is divided into qualified products and unqualified products according to its own shape. The screening process is carried out in the closed screening machine. The unqualified products are collected and reused as raw materials for production.
6. Packaging: The moisture content of the finished cat litter is about 8%, and it is in the form of long strips of particles. The qualified products are packaged by a packaging machine and put into storage for sale.

If you are interested in this tofu cat litter production line in Brazil project and want to build your own cat litter production line, please feel free to contact RICHI MACHINERY to obtain free cat litter factory construction plan, equipment quotation, process design and layout.
