Biomass Pelletizing Plant In Cameroon

RICHI MACHINERY

overview

This is a biomass pelletizing plant in Cameroon project that mainly processes biomass fuel pellets.

Biomass energy is the use of biomass to produce energy. Currently, biomass used as energy mainly refers to waste such as crop straw, forestry and wood processing.

Biomass can be converted into efficient solid, liquid and gaseous fuels to replace non-renewable energy such as coal, oil and natural gas. Biomass energy is an important renewable energy source. Increasing the development and utilization of biomass energy is of great significance to improving energy utilization and reducing greenhouse gas emissions. It is of great significance to protect the ecological environment.

Comprehensively utilizing solid waste such as discarded straw, rice husks, sawdust, etc. to produce biomass fuels, turning waste into treasure, reducing resource waste, promoting energy conservation and emission reduction, and reducing environmental pollution, has obvious social and environmental benefits.

To this end, the client of the project, an agricultural company from Cameroon, invested 160,000 US dollars to build a new annual production project of 5,000 tons of biomass pellets in the existing factory.

The raw materials of this biomass pelletizing plant in Cameroon project are sawdust, wood, straw, etc. The production process includes crushing, screening, granulation and other processes, with a total area of ​​about 480m2.

There are 6 employees in this project, and food and accommodation are not included. The annual working time is 300 days, and the working system is 8 hours.

RICHI MACHINERY

Main construction content and scale

The main contents of the biomass pellet plant in Cameroon project include crushing, screening and granulation production areas and environmental protection facilities. The main construction contents of the project are shown in the table below.

No.	Name	Content and scale	Remarks
Main engineering	Factory	Includes raw material storage area, crushing and screening processing area, particle production area, packaging area, product storage area, etc., covering an area of ​​about 480m2	Using the existing steel-concrete structure factory, fully enclosed
Auxiliary engineering	Office area	2F, covering an area of ​​about 60m2	Located next to the factory
Public engineering	Water supply	From local tap water	Newly built
	Power supply	Connected to local power station	Newly built
Environmental protection engineering	Waste gas	Dust from unloading, crushing, screening, granulation and packaging are discharged in closed workshops, with enhanced ventilation and timely cleaning of the ground	Newly built
	Wastewater	No production wastewater is generated; domestic wastewater is used as agricultural fertilizer after being treated in septic tanks and is not discharged	Newly built
	Noise	Reasonable layout, selection of low-noise equipment, sound insulation, vibration reduction measures, and enhanced management	Newly built
	Solid waste	Domestic garbage and waste packaging are collected and disposed of by the sanitation department	Newly built

RICHI MACHINERY

Main equipment for biomass pelletizing plant in Cameroon

The main equipment of this biomass pelletizing plant in Cameroon project is shown in the table below.

No.	Equipment Name	QTY
1	Biomass Crusher	2
2	Screening Machine	1
3	Conveyor Belt	4
4	Biomass Pellet Mill	2
5	Packaging Machine	2

RICHI MACHINERY

Main raw and auxiliary materials and energy consumption

The main raw and auxiliary materials consumption of this biomass pelletizing plant in Cameroon project is shown in the table below.

No.	Raw Material Name	Amount	Remarks
1	Wood chips, wood	3000t/a	Purchased raw materials are shipped into the factory in bags and scattered in the raw material storage area as raw materials for biomass pellets
2	Straw	3000t/a

RICHI MACHINERY

Cameroon Biomass Pellet Plant Project Process Design

This biomass pelletizing plant in Cameroon project uses the existing plant, and does not need to build a new plant. It mainly installs indoor equipment. The project construction work is small and the construction period is short. The project covers an area of ​​about 480m2.

In the existing plant, there are raw material storage area, crushing and screening processing area, pellet production area, packaging area, product storage area, office building, etc. arranged from north to south.

The equipment of the biomass pellet production line is arranged in sequence according to the process flow.

Brief description of the process flow of the project:

The raw materials of this biomass pelletizing plant in Cameroon project are sawdust, wood, straw, etc., which are transported by car to the raw material storage area and sent to the crusher for the first crushing, and then sent to the second crushing by the closed belt conveyor belt.

After screening, it goes through the pelletizing process, and then is transported to the packaging area by the closed belt conveyor belt. After packaging, it is stored in the product stacking area, and finally shipped by car for sale.

If you are interested in our Biomass Pelletizing Plant In Cameroon project, feel free to contact RICHI MACHINERY to customize the production line process plan and equipment configuration plan for free, and design civil engineering, equipment layout and other plans according to your factory.
