Bamboo Pellet Mill Plant In Thailand

RICHI MACHINERY

overview

In order to meet market demand, the project client, a bamboo products company, invested 220,000 US dollars to build a new project with an annual output of 3,000 tons of machine-made charcoal and 7,000 tons of bamboo pellets. It comprehensively utilizes local bamboo processing waste to produce bamboo charcoal, turning waste into treasure, opening up a new way for bamboo processing waste treatment, and achieving economic and environmental benefits.

Thailand has a warm and humid climate, which is suitable for bamboo growth. It has a large number of bamboo forests, which provide sufficient raw materials for processing. Bamboo chips can generally be used for fuel, papermaking, processing bamboo fiber, bamboo charcoal, etc. Among them, papermaking and processing bamboo fiber have higher costs and relatively more pollution; while processing bamboo charcoal has lower costs and relatively less pollution.

Bamboo charcoal is mainly used as activated carbon and barbecue fuel. It also has super strong adsorption capacity and releases negative ions. It has significant adsorption and decomposition effects on formaldehyde, benzene, ammonia and other major pollutants in indoor air and car air. The product has a wide range of applications and has good development prospects.

The total number of people in this bamboo pellet mill plant in Thailand project is 12, including 2 managers and 10 production workers, with an annual production day of 250 days. The crushing, drying and extrusion processes are produced for 8 hours a day, no production at night, and the carbonization process is produced continuously. The managers live in the factory, and the other 10 do not eat and stay in the factory.

RICHI MACHINERY

Why is Thailand suitable for bamboo pellet processing business?

In addition to its own rich bamboo resources, the Thai government encourages the development of renewable energy and environmental protection industries.

As a green industry, bamboo pellet processing may receive policy benefits. With the increase in global demand for renewable energy, bamboo pellets, as a biomass energy, have broad market prospects and are in demand in both the local and international markets in Thailand.

Thailand’s labor costs are relatively low, and bamboo grows rapidly, and the cost of raw materials is also low, which is conducive to reducing production costs. Bamboo pellet processing helps reduce dependence on fossil fuels, reduce carbon emissions, and is in line with environmental protection trends. Thailand has a certain amount of technical accumulation in the fields of agriculture and biomass energy, and can provide technical support for bamboo pellet processing.

RICHI MACHINERY

Project construction content

This bamboo pellet mill plant in Thailand project covers an area of ​​6667m2 and a construction area of ​​4500m2. The construction content of the project mainly includes: construction of carbonization pool, raw material storage area, production and processing workshop, auxiliary supporting projects, environmental protection projects, etc.

The biomass pellet plant project is entered from the north. The entire plot is in the shape of an east-west rectangular block. The east side is arranged as a raw material shed, which is followed by crushing, heating and drying, and rod making; the north side is a carbonization pool and office and living room; the northeast side is cooling and packaging, and the west side is a finished product warehouse.

The specific content of the bamboo pellet mill plant in Thailand project is shown in the table below:

No.	Engineering Classification	Construction Content	Occupied Area	QTY	Building Structure	Remarks
1	Main engineering	Production and Processing Workshop	800 m2	1	Brick-concrete	Mechanical Carbon Production Line
		Raw Material Storage Area	600m2	1	Steel Body	Not Crushed in the Factory, Stacking Loose Raw and Auxiliary Materials
		Finished Product Storage Area	800m2	1	Steel body	Pile up carbon
		Carbonation pool	1600m2	25	Brick and concrete	Used for carbonization
2	Auxiliary engineering	Office	200 m2	1	1F, brick and concrete	Office life

RICHI MACHINERY

Raw and auxiliary materials for the project

The main raw and auxiliary materials for this bamboo pellet mill plant in Thailand project are bamboo chips. There are many bamboo product processing companies in the local area, which have abundant sources of bamboo chips.

No.	Raw and auxiliary materials	QTY	Source
1	Bamboo chips	15000t/a	Raw materials come from legal manufacturers in the surrounding area
2	Water for desulfurization and dust removal	100t/a	Mountain spring water
3	Domestic water	120t/a	Mountain spring water
4	Electricity	100,000 kW·h/a	Supplied by the local power supply station
5	Fuel	125t/a	Using unqualified bamboo charcoal as fuel

RICHI MACHINERY

Processing technology design of Thai bamboo pellets

Description of bamboo pellet process flow:

1. Crushing: Place irregularly shaped and sized raw materials (bamboo chips, with a moisture content of about 50%) into a crusher and crush them into bamboo chips with uniform fineness of about 3mm.
2. Drying: Use a dryer to dry the crushed particles to a moisture content of between 6% and 12%.
3. Rod making: The crushed and dried raw materials are made into hollow strip semi-finished firewood sticks under the high temperature and high pressure of the rod making machine. The size of the firewood stick is: 2~6cm in diameter and 40~50cm in length.
4. Carbonization: Stack the semi-finished firewood sticks neatly in the carbonization pool, seal the air inlet, ignite, control the oxygen intake during combustion, and carbonize into charcoal. The carbonization process can generally be divided into three stages:
   • Drying stage: The project ignites the formed bamboo chips sticks. From the ignition to the furnace temperature rising to 160℃, the moisture contained in the machine-made sticks mainly evaporates by external heat and the heat generated by its own combustion. The chemical composition of the machine-made sticks has hardly changed.
   • Initial stage of carbonization: In this stage, the heat is mainly generated by the combustion of the sticks themselves, which raises the kiln temperature to between 160 and 280°C. At this time, the bamboo material undergoes thermal decomposition reaction, and its composition begins to change. Among them, unstable components, such as hemicellulose, decompose to produce CO2, CO and other substances.
   • Full carbonization stage: In this stage, the bamboo material undergoes rapid thermal decomposition, and a large amount of liquid products such as bamboo tar and bamboo vinegar are generated. In addition, combustible gases such as methane and ethylene are also generated. The combustible gas (gas product) actually generated during the carbonization and pyrolysis process of this project enters the pipeline for drying and combustion. During the pipeline transportation process, due to cooling, there will be condensed liquid products, namely bamboo vinegar and bamboo tar.
5. Pelletization: The dried wood chips are sent to the biomass bamboo pellet machine for extrusion molding.

RICHI MACHINERY

equipment for Thailand bamboo pellet processing project

The main equipment used in this bamboo pellet mill plant in Thailand project is detailed in the table below:

No.	Equipment Name	QTY
1	Conveyor Belt	2
2	Auger	3
3	Rolling Screen	1
4	Drying Equipment	1
5	Suspended Dust Collector	2
6	Blower	2
7	Crusher	2
8	Roller	2
9	Desulfurization Tower	1
10	Carbonization Pool	25
11	Biomass Pellet mill	1

RICHI MACHINERY

Public works

① Water supply:

The water used in this bamboo pellet mill plant in Thailand project is supplied by mountain spring water, and the water is mainly used for employees’ daily life and circulating water pool replenishment.

② Drainage:

There is no production wastewater discharge in this project; the initial rainwater is collected and precipitated, and is reused for sprinkling and dust reduction; the amount of domestic sewage generated is small, and it is treated in a septic tank and reused for green land irrigation or regular cleaning as agricultural fertilizer, so that domestic sewage is not discharged.

③ Power supply:

The power supply is connected from the nearby power grid to each power consumption area of ​​this project, and the power consumption of the project is expected to be 100,000 kW·h/a.

④ Energy:

The energy used in the operation of the project is mainly electricity, biomass molding fuel and other energy sources, and the project does not use coal as fuel.

The overall layout of the project has clear functional divisions and clear streamlines, and each link does not interfere with each other, ensuring the smooth operation of the project; the equipment is placed in a centralized manner, and pollutants can be concentratedly reduced and isolated; from the aspects of process flow, material transportation, and environmental protection, the plane layout of this project is reasonable.

In addition to this bamboo pellet mill plant in Thailand project, we have also built many animal feed production lines, biomass pellet production lines and organic fertilizer production line, cat litter production line projects in Thailand. If you also want to invest in bamboo pellet production lines or other pellet processing projects, feel free to contact RICHI MACHINERY to obtain information such as full plant design, equipment layout, civil engineering, production line 3D design, equipment quotation, delivery plan, etc.
